- Frequency range of 10 kHz to 10 MHz
- Fully compliant with MIL-STD 461
- “Air-core” inductors to prevent saturation
- Individual Calibration Included
- Three-Year Warranty
LI-400C
LISN 25 Amps for MIL-STD 461
The LI-400C Line Impedance Stabilization Network (LISN) provides the necessary measurement platform for performing power line conducted emissions compliance testing as required by most worldwide standards for commercial products. The LI-400C is compliant with MIL-STD 461.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Product Name | Line Impedance Stabilization Network (LISN) |
| Specification | MIL-STD 461 |
| Application | Power Line conducted emission tests |
| Frequency Range | 10KHz - 10 MHz |
| RF Connector | 50 Ohms N-type (female) |
| Current Rating | 25 Amp |
| Voltage Rating | 270 VAC (Line to Ground) 50/60 Hz, 135 VAC (Line to Ground) 400 Hz, 380 VDC |
| Inductors | 50 microhenry (air-core) |
| Mains & EUT Connections | Superior Electric SUPERCON Shrouded sockets |
| Dimensions (each network) | 13 x 7 x 7 inches / 33 x 17.7 x 17.7 cm |
| Weight (each network) | 14 lbs / 6.3 kg |
