- Compliant with RTCA DO-160 and MIL-STD-461 standards for conducted emissions testing.
- Frequency range from 10 kHz to 400 MHz for wide EMC coverage.
- 50Ω N-type female RF connector ensures accurate measurement performance.
- Handles up to 50 Amperes with AC and DC voltage support.
- 5 µH air-core inductors prevent saturation and maintain stability.
- Superior Electric SUPERCON® shrouded sockets for safe, reliable connections.
- Individually calibrated with a certificate for precise results.
- Three-year manufacturer warranty guarantees product reliability.
LI-350
LISN for CISPR 25 & 16-1-2, DO-160, FAA, MIL-STD 461
The LI-350 Line Impedance Stabilization Network (LISN) provides the necessary measurement platform for performing power line conducted emissions compliance testing as required by most worldwide standards for commercial products. The LI-350 is compliant with both RTCA DO-160 and MIL-STD-461. The LISN provides defined stable impedance and isolates the EUT from power source influences, thereby providing accurate and repeatable results
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Product Name | Line Impedance Stabilization Network (LISN), Model LI-350 |
| Standards Compliance | RTCA DO-160 and MIL-STD-461 |
| Application | Power line conducted emissions testing for commercial and military products |
| Frequency Range | 10 kHz to 400 MHz |
| RF Connector | 50Ω N-type (female) |
| Current Rating | 50 Amperes maximum |
| AC Voltage Rating | 480 VAC (50–400 Hz), 270 VAC (800 Hz) |
| DC Voltage Rating | 600 VDC maximum |
| Inductors | 5 µH air-core inductors |
| Mains & EUT Connections | Superior Electric SUPERCON® shrouded sockets |
| Calibration | Individually calibrated with certificate and test data |
| Warranty | Three-year manufacturer warranty |
