- Frequency range of 10 kHz to 10 MHz
- Fully compliant with MIL-STD 461
- 100 Amp(AC) (forced air cooling)
- “Air-core” inductors to prevent saturation
- Individual Calibration Included
- Three-Year Warranty
LI-4100
LISN 100 Amps For MIL-STD 461
The LI-4100 Line Impedance Stabilization Network (LISN) provides the necessary measurement platform for performing power line conducted emissions compliance testing as required by most worldwide standards for commercial products. The LI-4100 is compliant with MIL-STD 461.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Product Name | Line Impedance Stabilization Network (LISN) |
| Specification | MIL-STD 461 |
| Application | Power Line conducted emission tests |
| Frequency Range | 10 kHz to 10 MHz |
| RF Connector | 50 Ohms N-type (female) |
| Current Rating | 100 Amperes |
| Voltage Rating | 525 VAC (Line to Ground) 50/60 Hz, 270 VAC (Line to Ground) 400 Hz, 135 VAC (Line to Ground) 800 Hz, 600 VDC |
| Inductors | 50 microhenry (air-core) |
| Mains & EUT Connections | Superior Electric SUPERCON Shrouded sockets |
| Dimensions (each network) | 10 x 10 x 21 inches /25.4 x 25.4 x 53.3 cm |
| Weight (each network) | 17 lbs. / 7.7 kg |
