- Frequency Range: 150 kHz to 30 MHz (for emissions - as ISN) 150 kHz to 230 MHz (for immunity - as CDN)
- Screened Lines (up to four balanced pairs)
- Meets CISPR 16-1-2, CISPR 22/32 (EN 55022/32) and IEC 61000-4-6
- Individual Calibration Included
ISN / CDN-T8SE
ISN / CDN for RJ-45 Shielded
The CDN-T8SE is designed for conducted emissions and immunity testing on devices with shielded telecom ports supporting up to four balanced pairs. It features shielded RJ45 connectors for EUT and AE ports, a BNC RF I/O connector on the top side, and a durable powder-coated metal enclosure mounted on a conductive stainless steel base plate for effective grounding. The CDN-T8SE can be purchased individually or as part of a CIS series conducted immunity test system, which includes an ACS series power amplifier and required accessories.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Product Name | Coupling Decoupling Network (CDN) |
| Compliant Test Standards | IEC / EN 61000-4-6 |
| Application | Four screened, balanced pairs |
| Frequency Range | 150 kHz to 230 MHz |
| RF Input Voltage | 40 V (Max) |
| RF Input Connector | 50 Ω BNC (Female) |
| Voltage Rating | 124 V AC / 125 V DC (Line to Ground) |
| Current Rating | 1.5 Amp (Max) |
| AE and EUT Connections | 50 Ohm Female BNC |
| Common Mode Impedance | 150 kHz - 26 MHz: 150Ω ± 20Ω; 26 MHz - 80 MHz: 150Ω + 60Ω / – 45Ω; 80 MHz - 230 MHz: 150Ω + 60Ω / – 60Ω |
| Voltage Division Factor | 9.5 dB +1.5/ -0.5 |
| Decoupling of Common Mode Disturbance | 150 KHz ≥ 45dB (RF/AE); 500 KHz ≥ 50dB (RF/AE); 230 MHz ≥ 50dB (RF/AE) |
| Dimensions | 8.5 x 4.5 x 3.5 inches or 21.5 x 11.4 x 8.8 cm |
| Weight | 2 lbs. or 0.9 kg |
