- Frequency Range 150 MHz to 230 MHz
- Designed for IEC / EN 61000-4-6
- 50 Ohm Coaxial Cables
- Individual calibration included
- Three Year Warranty
ISN / CDN-C50E
ISN / CDN for 50 ohm Coax Cable
The CDN C50E is used on coaxial lines with a nominal transmission line impedance of 50 ohms. The EUT and AE Ports are fitted with female, 50Ω BNC-type coaxial connectors. The RF Port is also fitted with a female, 50Ω BNC-type coaxial connector. The outer surface of the network’s metallic enclosure is powder coated for durability, and is mounted onto, and internally bonded to, an untreated (conductive) stainless steel base plate. The base plate extends beyond the footprint of the network enclosure at the front and back, providing convenient access to effectively ground the network, which is essential for proper operation.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Product Name | Coupling Decoupling Network (CDN) |
| Compliant Test Standards | IEC / EN 61000-4-6 |
| Application | 50 Ohm Coaxial Cables |
| Frequency Range | 150 kHz to 230 MHz |
| RF Input Voltage | 40 V (Max) |
| RF Input Connector | 50 Ω BNC (Female) |
| Voltage Rating | 310 V AC / 440 V DC (Line to Ground) |
| Current Rating | 1 Amp (Max) |
| AE and EUT Connections | 50 Ohm Female BNC |
| Common Mode Impedance | 150 kHz - 26 MHz: 150Ω ± 20Ω; 26 MHz - 80 MHz: 150Ω + 60Ω / – 45Ω; 80 MHz - 230 MHz: 150Ω + 60Ω / – 60Ω |
| Voltage Division Factor | 9.5 dB +3 / -1 |
| Decoupling of Common Mode Disturbance | ≥ 40dB (EUT/AE) |
| Dimensions | 6 x 6 x 13 inches or 15.2 x 15.2 x 33 cm |
| Weight | 5 lbs. or 2.3 kg |
