- Built-in discharge resistor for safety
- Excellent stability with long life
- High insulation resistance
- Allows bulkhead or bench mounting
CFT-10U
Feed Through Capacitor
The CFT-10u Feed-Thru Capacitors are ruggedly constructed are highly reliable units for general use in shielded enclosures and other environments. The capacitors have four threaded mounting holes for easy installation onto a metal enclosure. Power connections are made to their M6x1 threaded feed-thru stud. They are rated for currents up to 100 Amps without heating or voltage loss. These capacitors feature low dissipation factors, high temperature ratings, high insulation resistance, double the rated dielectric strength, and long life. For safety purposes, a parallel bleeder resistor is incorporated internally in order to discharge the capacitor when the applied voltage is removed.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Capacitance | 10 µF ±10% |
| Current | 100 Amp at 40 degrees C |
| Voltage | 275 VAC RMS (60 Hz), 250 VAC RMS (400Hz), 600 VDC |
| Temperature | -55°C to +70°C @ rated voltage +105°C @ 50% of rated voltage |
| Dissipation factor | Less than 1% at 25°C (measured at 120 Hz) |
| Dielectric strength | Twice the rated VDC @ 25°C for two minutes |
| Bleeder Insulation resistance | 1.5 MΩ + 5 % @ 25°C rated voltage. |
| Insulation Resistance | 100MΩ prior to adding bleeder resistance |
| Construction | Brass, Nickel Plated |
