- Frequency Range: 150 kHz to 230 MHz (extended range: 10 kHz to 1 GHz)
- Designed for IEC/EN 61000-4-6
- Extremely Efficient Coupling
- Establishes both Capacitive and Inductive Coupling to the EUT Cable.
- Three-Year Warranty
CLEM-6146
Electromagnetic Clamp
CLEM-6146 EM Clamp is a clamp injection device designed for conducted immunity testing in accordance with IEC/EN 61000-4-6, covering a frequency range of 150 kHz to 230 MHz, with extended operation up to 1 GHz. It couples RF energy onto the cable between the EUT and auxiliary equipment, directing the interference toward the EUT while decoupling the AE path. Featuring a split-core ferrite design with a hinged enclosure, the clamp allows easy cable placement and secure locking for reliable and repeatable testing.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Product | EM Clamp |
| Frequency Range | 150 kHz to 230 MHz |
| Extended Frequency Range | 10 kHz to 1 GHz |
| Nominal Impedance | 50 Ω |
| Input Connector | Type-N (female) |
| Clamp Opening Diameter | 0.79" (20 mm) |
| Maximum Cable Diameter | 0.75" (19 mm) |
| Height of Center of Cable Opening | 2" (50.3 mm) |
| Distance from Either End of Clamp to Reference Point | 0.87" (22 mm) |
| 10 kHz to 100 MHz | 100 W for 15 minutes |
| 100 MHz to 230 MHz | 100 W for 3 minutes |
| 230 MHz to 1 GHz | 50 W for 3 minutes |
| Dimensions (L × W × H) | 25.6" × 4.9" × 4.9" (650.2 × 124.5 × 124.5 mm) |
| Weight | 13 lbs (5.9 kg) |
