- Quick, Pre-Test Site Validations
- Wide Frequency Range 1 MHz to 1.5 GHz
- Battery Operated - Extended Battery Life operates >18 hours per charge
- Automatic Low-Battery Voltage Shut-off
- User-selectable Output Frequency/Step Size
- Three-Year Warranty
CG-515
Comb Generator 1 and 5 MHz Stepsize
CG-515 Comb Generator is a compact and lightweight radiated and conducted reference signal source covering 1 MHz to 1.5 GHz, with user-selectable 1 MHz or 5 MHz increments. It includes two interchangeable antennas for optimal performance across low and high frequencies. Designed for battery operation, the CG-515 minimizes unwanted reflections and delivers up to 18 hours of continuous use on a full charge. Features such as low-battery indication and automatic shut-off ensure stable and reliable output. A custom carrying case is included for convenient transport and storage.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Intended Application | Radiated Reference Signal Source (for OATS, SAC, FAC, etc.) |
| Frequency Range | 1 MHz to 1.5 GHz |
| Frequency Step Size | 1 MHz or 5 MHz (user-selectable) |
| Frequency Stability | 20 ppm |
| Amplitude Stability | ± 0.1 dB |
| Time Stability | <1 dB over 12 months |
| Charging Adapter Output | 6 VDC (unregulated), 500 mA |
| Battery Type | 6V NiMH, 1 Ah |
| Battery Operation | >18 Hours Typical (fully-charged battery) |
| External LED Indicators | Battery Low, Power On |
| Antenna Type | (2) Monopoles (3-inch & 12-inch) |
| Generator Dimensions | (HxWxD) 2.9 in. x 3.1 in. x 3.1 in. (7.4 x 7.9 x 7.9 cm) |
| Weight | 0.5 lbs (0.2 kg) |
