- Frequency Range 150 MHz to 230 MHz
- Designed for IEC / EN 61000-4-6
- Four wire unscreened, unbalanced cables
- Individual calibration included
- Three Year Warranty
CDN-AF4E
CDN 4 wire Unscreened Audio Frequency
The Com-Power CDN-AF4E is a Coupling/Decoupling Network designed for conducted immunity testing in accordance with IEC/EN 61000-4-6 and CISPR 16-1-2. It is intended for products using four-wire unscreened data communication cables and features four 2 mm shrouded banana sockets on both the EUT and AE sides, with a current handling capability of up to 5 A. RF disturbance signals are injected via a BNC connector supporting up to 40 V input, and the unpainted base ensures proper grounding. Each unit is individually calibrated and can be purchased separately or as part of Com-Power’s CIS series conducted immunity test system.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Product Name | Coupling Decoupling Network (CDN) |
| Compliant Test Standards | IEC / EN 61000-4-6 |
| Application | Four wire unscreened, unbalanced Cables |
| Frequency Range | 150 kHz to 230 MHz |
| RF Input Voltage | 40 V (Max) |
| RF Input Connector | 50 Ω BNC (Female) |
| Voltage Rating | 310 V AC / 440 V DC (Line to Ground) |
| Current Rating | 5 Amp (Max) |
| AE and EUT Connections | 2 mm shrouded banana sockets |
| 150 kHz - 26 MHz | 150Ω ± 20Ω |
| 26 MHz - 80 MHz | 150Ω + 60Ω / – 45Ω |
| 80 MHz - 230 MHz | 150Ω + 60Ω / – 60Ω |
| Voltage Division Factor | 9.5 dB +3 / -1 |
| Decoupling of Common Mode Disturbance | ≥ 40dB (EUT/AE) |
| Dimensions | 6 x 6 x 13 inches or 15.2 x 15.2 x 33 cm |
| Weight | 5 lbs. or 2.3 kg |
