- Frequency Range 150 kHz to 230 MHz
- Designed for IEC / EN 61000-4-6
- One unscreened, balanced pair
- Individual calibration included
- Three Year Warranty
CDN-T2E
CDN for One Balanced Unscreened Pair
The Com-Power CDN-T2E is a Coupling/Decoupling Network designed for conducted immunity testing in accordance with IEC 61000-4-6 and CISPR 16-1-2. It is intended for products using unscreened balanced pair communication cables, such as telecom lines, and features RJ11 connectors on both the EUT and AE sides, with a current handling capability of up to 2 A. RF disturbance signals are injected via a BNC connector supporting up to 40 V input, and the unpainted base ensures proper grounding. Each unit is individually calibrated and can be purchased separately or as part of Com-Power’s CIS series conducted immunity test system.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Product Name | Coupling Decoupling Network (CDN) |
| Compliant Test Standards | IEC / EN 61000-4-6 |
| Application | One unscreened, balanced pair |
| Frequency Range | 150 kHz to 230 MHz |
| RF Input Voltage | 40 V (Max) |
| RF Input Connector | 50 Ω BNC (Female) |
| Voltage Rating | 124 V AC / 125 V DC (Line to Ground) |
| Current Rating | 2 Amps (Max) |
| AE and EUT Connections | RJ 11 |
| 150 kHz - 26 MHz | 150Ω ± 20Ω |
| 26 MHz - 80 MHz | 150Ω + 60Ω / – 45Ω |
| 80 MHz - 230 MHz | 150Ω + 60Ω / – 60Ω |
| Voltage Division Factor | 9.5 dB +4 / -1 |
| Dimensions | 8.5 x 4.5 x 3.5 inches or 21.5 x 11.4 x 8.8 cm |
| Weight | 5 lbs. or 2.3 kg |
