- Frequency Range 30 - 1000 MHz
- Test to CISPR 14 (EN 55014) requirements
- Individual Calibration
- Two Year Warranty
CLA-150
Absorbing Clamps
The CLA-050 and CLA-150 Absorbing Clamps are designed to measure disturbance power on power input lines as well as other auxiliary I/O lines. The measurement of disturbance power is a method for determination of radiated disturbance, and an alternative to the measurement of disturbance field strength on an Open Area Test Site (OATS) or Semi-Anechoic Chamber (SAC)
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency Range | 30 - 1000 MHz |
| Impedance | 50 Ohm |
| Connector Type | BNC (f) |
| Max cable diameter | 32 mm (1.26 inches) |
| Aperture size | 34.9 mm (1.37 inches) |
| Weight | 21 lbs (9.5 Kg) |
| Dimensions | 627 x 114 x 165 mm (24.7 x .4.5 x 6.5 inches) |
