- Broadband Antennas
- High Gain Preamplifier
- Near Field Probe Kit
- Comb Generator
- Carrying Case
- Three-year Warranty
ANK-310
Antenna Kit
The ANK-310 is one of the five portable antenna kits offered by Com-Power. This kit includes the necessary antennas, preamplifier and measurement cables for pre-compliance or qualification level radiated emissions testing in the 30 MHz to 1 GHz frequency range, as well as a Comb Generator for test site verifications and a nearfield probe set for troubleshooting EMI problems. The entire kit is smartly arranged within a single, durable, compartmentalized carrying case with wheels for easy transport.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency Range | 30 MHz to 1 GHz |
| AB-900A Biconical Antenna | 25 MHz to 300 MHz (Collapsible Elements) |
| ALC-100 Compact Log Periodic Antenna | 300 MHz to 1 GHz |
| PAM-103 Preamplifier | 33 dB Gain, 1 MHz to 1 GHz |
| CGO-501 / CGO-505 Comb Generator | 1 MHz or 5 MHz Step |
| PS-500 Near Field Probes | 400 Hz to 5 GHz |
| Cables | N and BNC Type |
| Calibration Data | Included |
| Optional Accessory | AT-812 Antenna Tripod with ATC-812 Carrying Case |
| Weight | 54 lbs / 24.5 kg |
| Dimensions | 27 × 22 × 10 inches (68.5 × 55.8 × 24.4 cm) |
