- Porduct Model: CLA-050
- Frequency Range: 30 MHz to 1 GHz
- Clamp Factor: -4 to +5 dBpW/µV [-17 + clamp Insertion loss]
- Clamp Insertion loss: 13 dB to 22 dB
- Decoupling Factor (DF): >21 dB
- Decoupling Factor (DR): >30 dB
- RF Connector: 50Ω - BNC (female)
- Operating Current: 20 A (max.)
- Operating Temperature: 40°F to 104°F (5°C to 40°C)
- Aperture Diameter: 0.5 inch
CLA-050
Absorbing Clamps
The CLA-050 and CLA-150 Absorbing Clamps are designed to measure disturbance power on power input lines as well as other auxiliary I/O lines. The measurement of disturbance power is a method for determination of radiated disturbance, and an alternative to the measurement of disturbance field strength on an Open Area Test Site (OATS) or Semi-Anechoic Chamber (SAC)
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Porduct Model | CLA-050 |
| Frequency Range | 30 MHz to 1 GHz |
| Clamp Factor | -4 to +5 dBpW/µV [-17 + clamp Insertion loss] |
| Clamp Insertion loss | 13 dB to 22 dB |
| Decoupling Factor (DF) | >21 dB |
| Decoupling Factor (DR) | >30 dB |
| RF Connector | 50Ω - BNC (female) |
| Operating Current | 20 A (max.) |
| Operating Temperature | 40°F to 104°F (5°C to 40°C) |
| Aperture Diameter | 0.5 inch |
