- Compliant with IEC 61000-4-5 Surge Waveform Requirements
- →1.2/50, 8/20 µs Combination Wave
- →10/700, 5/320 µs Combination (Telecom) Wave
- Can be operated via front panel interface or \ remote PC through fiber optic interface with TransWare-645 software
- Voltage (1000x1) and Current (100x1) Monitor Ports located on front panel.
- Internal Power Line CDN (up to 16 Amps AC)
- External Power Line CDNs Available with AC current ratings up to 100 Amps
- Three-Year Warranty
SGIEC-645
Surge Generator for IEC 61000-4-5 Testing
The SGIEC-645 is a state of the art, compliance level Surge Generator designed for IEC 61000-4-5 surge immunity testing. It is capable of generating both the 1.2/50, 8/20
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Product Type | Surge Generator for IEC 61000-4-5 testing |
| Surge Waveforms | 1.2/50 µs & 8/20 µs combination waves | 10/700 µs & 5/320 µs telecom waves |
| Output Voltage Range | 200 V to 4000 V adjustable in 1 V steps |
| Surge Polarity | Positive | Negative | Alternating |
| Phase Synchronization | 0° to 359° adjustable |
| Time Between Surges | 20–600 s / 35–600 s depending on waveform |
| Monitor Ports | Voltage 1000:1 | Current 100:1 | Sync output 0–5 V |
| Input Power | 100–250 VAC 50/60 Hz 300 VA max |
| Internal CDN Ratings | Up to 250 VAC 16 A | 100 VDC various current levels |
| Connectors | IEC power inlet | Safety interlock | Fiber optic port | BNC monitor outputs |
| Dimensions (H × W × D) | 7.75″ × 19″ × 26.7″ (4U rack size) |
| Weight | 24.3 kg / 53.5 lbs |
| Operating Temperature | 5°C to 40°C |
| Cooling Method | Forced air |
| Warranty | 3 years |
