SGTEL-168

Surge Generator for Telecom Testing for FCC Part 68

The SGTEL-168 is a versatile surge generator designed to simulate all the environmental surge transients as described in FCC TIA-968-B (formerly known as Part 68) and Industry Canada CS03 standard. It provides a single box solution Type A, Type B (metallic and longitudinal) and Powerline surges. These surges simulate the effect of lightning on telecom equipment under test. So it is also referred to as Lightning Simulator. The electromagnetic energy from the lightning couples into the equipment by powerline or telecom cable exposed to the lightning directly or indirectly. This model is an upgraded version of SG-168 with windows software control and a user friendly front panel for manual operation.

Datasheet

Features

Key capabilities and advantages

▼

Complies to FCC TIA-968-B and CS03 standards
Standard Test routines software and manual operations
Built-in CDN for AC power ports
Fiber optic RS232 interface
Lightning Simulator

Specification

Technical specifications and parameters

▼

Product Type	Telephone Line Surge Generator for IEC 61000-4-5 testing
Surge Waveforms	1.2/50 µs & 8/20 µs combination waves
Output Voltage Range	200 V to 4000 V adjustable
Surge Polarity	Positive \| Negative \| Alternating
Line Types Supported	Single line \| Two-line \| Three-line test configurations
Impedance	60 Ω typical
Synchronization	Adjustable phase
Time Between Surges	Adjustable timing
Monitor Ports	Voltage monitor output \| Current monitor output \| Sync output
Input Power	100–250 VAC 50/60 Hz
Connectors	Telephone line surge ports \| Power inlet \| Monitor ports
Dimensions (H × W × D)	Standard rack size
Weight	Standard test unit weight
Operating Temperature	Standard operating range
Cooling Method	Forced air
Warranty	3 years
