- All-Digital IF Technology
- Frequency Range from 9 kHz up to 3.2 GHz
- -161 dBm/Hz Displayed Average Noise Level (Typ.)
- -98 dBc/Hz @10 kHz Offset Phase Noise (1 GHz, Typ.)
- Total Amplitude Accuracy < 0.7 dB
- 1 Hz Minimum Resolution Bandwidth (RBW)
- Standard Preamplifier
- Up to 3.2 GHz Tracking Generator Kit
- EMI Pre-compliance Test Kit
- 10.1 lnch WVGA(1024x600)Display
SPA-900TG Series
Spectrum Analyzers for EMI-EMC Testing
SPA -900 Series Spectrum Analyzers from Com-Power of have a frequency range of 9 kHz up to 3.2 GHz. With their light weight, small size, and friendly user interface, the SPA-900TG offer a bright easy to read display, powerful and reliable automatic measurements, and plenty of powerful features. Applications include broadcast monitoring/evaluation, site surveying, EMI precompliance, research and development, education, production, and maintenance.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Model | SPA-932TG |
| Frequency Range | 9 kHz~3.2 GHz |
| Resolution Bandwidth | 1 Hz~1 MHz, in 1-3-10 sequence |
| Displayed Average Noise Level | -161 dBm/Hz, Normalize to 1 Hz (typ.) |
| Phase Noise Amplitude Precision | < -98 dBc/Hz@1 GHz, 10 kHz offset |
| Model | SPA-921TG |
| Frequency Range | 9 kHz~2.1 GHz |
| Resolution Bandwidth | 1 Hz~1 MHz, in 1-3-10 sequence16 |
| Displayed Average Noise Level | -161 dBm/Hz, Normalize to 1 Hz (typ.) |
| Phase Noise Amplitude Precision | < -98 dBc/Hz@1 GHz, 10 kHz offset |
