- Small Form Factor
- Extremly Portable
- Perfect Preamp for Near Field Probe Sets
PAP-501
Preamplifier for Sniffer Probes
Intended for improving system sensitivity Model PAP-010 Preamplifier is used with near field probes. It has a frequency range of 10 to 1000 MHz. It is compact in size and is powered by external DC adapter.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency | 10 MHz - 1000 MHz |
| Application | EMI / EMC Measurements |
| Gain | 21 dB |
| Gain Flatness | ± 2 dB |
| PIdB | +10 dBm |
| Max Input | 2 VDC, +10 dBm |
| Impedance | 50 Ohms |
| Connector Type | BNC |
| Power | 6 VDC, 0.5 A |
| Size | 83 x 42 x 25 mm (3.27 " x 1.65" x 0.985") |
| Weight | 1 lb. (0.45 kg) |
