- Wide frequency range from 150 kHz to 250 MHz for EMC testing.
- Delivers 100 watts of rated power output into a 2:1 VSWR load.
- Provides 50 dB gain with ±2 dB variation for consistent performance.
- No compression up to 100W, ensuring clean signal amplification.
- Supports AM, FM, and pulse modulated input signals.
- Low harmonic distortion of -15 dBc at 100 watts output.
- Automatic shutoff if VSWR exceeds 7 for safety.
- Front panel LCD displays current, temperature, power, VSWR, and gain.
- USB interface allows automation and easy integration.
- Includes a 3-year warranty for long-term reliability.
ACS-250-100W
Broadband Power Amplifier 100 Watts for Conducted Immunity
The Com-Power ACS-230 series are broadband RF amplifiers designed for IEC 61000-4-6 immunity testing with CDNs. They offer high gain, efficiency, and reliable performance at an affordable price, easily achieving 3 Vrms or 10 Vrms test levels with compliant coupling networks. Each unit is individually tested to meet IEC 61000-4-6 requirements and can be paired with matching CDNs, accessories, and optional automation software for a complete test setup. All units include a 3-year warranty.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency Range | 150 kHz to 250 MHz |
| Rated Power Output | 100 watts into 2:1 VSWR |
| Gain | 50 dB ±2 dB |
| Input for rated output | 0 dBm (typical) |
| Automatic Safety Shut-off | 140 watt |
| Power Output @ 1 dB Compression Point | No Compression unit 100 W |
| VSWR | 1.7 (maximum |
| Input Signal Modulation Compatibility | AM, FM, or Pulse modulation |
| Connector | Type N on Front Panel |
| Impedance | 50 ohms (nominal) |
| VSWR | 1.7 (maximum) |
| Harmonic distortion | 15 dBc at 50 watts |
| Mismatch Tolerance | Automatic Safety Shut-off @ VSWR >7 |
| Connector | Type N on Front Panel |
| Power | (Universal) |
| AC, Single Phase | 100-240 VAC 50/60 Hz |
| Display and Interfaces | USB Remote Interface |
| Front Panel Display (Column 1) | Amplifier Current measurement Data |
| Front Panel Display (Column 2) | Amplifier Temperature measurement data |
| Front Panel Display (Column 3) | Load VSWR, RF Power Input/Output, Gain |
| Remote Interlock (optional) | 2-pin DIN |
| Cooling | Forced air (self-contained fans) |
| Size | 19” Rack 4U |
| Weight | 47 lbs (21.4 kg) |
| Operating Temperature Range | 0° C to +40° C |
