- From 150 kHz - 250 MHz
- Suitable for IEC-61000-4-6 testing
- Automatic Safety Shutoff
- Three year warranty
ACS-230-50W
50 W Power Amplifier for Conducted Immunity
The Com-Power ACS-230 series are broadband RF amplifiers designed for IEC 61000-4-6 immunity testing with CDNs. They deliver high gain, reliable performance, and efficient output at a cost-effective price. These amplifiers easily achieve 3 Vrms or 10 Vrms test levels using compliant coupling networks and meet all required specifications for compliance or pre-compliance testing.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency Range | 150 kHz to 230 MHz |
| Rated Power Output | 50 watts into 2:1 VSWR |
| Gain | 47 dB ±2 dB |
| Input for rated output | 0 dBm (typical) |
| Automatic Safety Shut-off | 50 watts ± 2 |
| Power Output @ 1 dB Compression Point | N/A |
| VSWR | 1.7 (maximum) |
| Input Signal Modulation Compatibility | AM, FM, or Pulse modulation |
| Connector | Type N on Front Panel |
| Impedance | 50 ohms (nominal) |
| VSWR | 1.7 (maximum) |
| Harmonic distortion | -17 dBc at 50 watts |
| Mismatch Tolerance | Automatic Safety Shut-off @ VSWR >7 |
| Connector | Type N on Front Panel |
| Power | (Universal) |
| AC, Single Phase | 100-240 VAC 50/60 Hz |
| Display and Interfaces | USB Remote Interface |
| Front Panel Display (Column 1) | Amplifier Current measurement Data |
| Front Panel Display (Column 2) | Amplifier Temperature measurement data |
| Front Panel Display (Column 3) | Load VSWR, RF Power Input/Output, Gain |
| Remote Interlock (optional) | 2-pin DIN |
| Cooling | Forced air (self-contained fans) |
| Size | 19” Rack 4U |
| Weight | 50 lbs (22.6 kg) |
| Operating Temperature Range | 0° C to +40° C |
