AFM-1500

Power Amplifiers for FM transmitters: 1500 W, 2000 W, 3000 W

A part of Com-Power's series of RF amplifiers, specifically geared for FM Broadcasting. The AFM-1500 model is a Wideband MOSFET amplifier, engineered to provide excellent operational efficiency and reliability. It has 1500 Watts nominal power output. The AFM-1500 is compatible with BEL (type HVB/HVM 164A, HVM 165A) or GCEL (type 131/136) 2x3 kW /2x5 kW FM Radio Transmitters. The phase and gain of the power amplifiers are matched to use them for high power FM Transmitters, i.e. two amplifiers output can be combined for 3 kW transmitters or four amplifiers for 5 kW transmitters.

Features

Key capabilities and advantages

▼

87.5 MHz - 108 MHz
1500 Watts
3 years warranty
CPAAT
CPAS
USB Interface

Specification

Technical specifications and parameters

▼

Frequency Range	87.5 kHz to 108 MHz
Rated Power Output	1500 watts
Input for rated output	2.5 Watts (max)
RF Checkpoint at output	0.707 Vrms (+10 dBm max.)
VSWR	1.2:1 (maximum)
Input Signal Modulation Compatibility	FM
Connector	Type BNC on Rear Panel
Impedance	50 ohms (nominal)
VSWR	1.2:1 (maximum)
Harmonic distortion	65 dBc (min) at 1500 watts
Mismatch Tolerance	Automatic Safety Shut-off @ VSWR >1.8
Connector	Type 7/16” on front panel
Power Amplifier Supply	27 VDC, 100 A (external)
Controller Supply	+/- 12 VDC, 1 A (external)
Power Consumption	2200 Watts (max)
Efficiency	68% (min)
Display and Interfaces	USB Remote Interface
Front Panel Display (Column 1)	Individual Modules current measurement data
Front Panel Display (Column 2)	Individual Modules temperature measurement data
Front Panel Display (Column 3)	Load VSWR, RF Power Input/Output, Gain
Cooling	Forced air (self-contained fans)
Size	19” Rack 3U
Weight	75 lbs (34 kg)
Operating Temperature Range	0° C to 30° C
