- Designed specifically to amplify low-frequency loop antenna signals.
- Works with loop antennas in the 9 kHz to 30 MHz range.
- Improves sensitivity and signal quality for EMC measurements.
- Low noise performance to preserve signal integrity.
- Rugged and compact design for lab and field use.
- Easy integration with spectrum analyzers and measurement receivers.
TBLNA-9K30
Loop Antenna Pre-Amplifier
The TBLNA-9K30 is a pre-amplifier for the TBMA6-P, expanding the dynamic range of the passive loop antenna. The pre-amplifier is designed for the TBMA6-P, but it can be used together with any passive loop antenna for the frequency range 9 kHz – 30 MHz. The pre-amplifier is equipped with a charger for 12 pieces standard AA NiMh batteries. A ¼” thread at the bottom of the TBLAA1 permits connectivity to standard tripods.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency range | 9 kHz to 30 MHz |
| Gain | 43 dB, typ. |
| Input return loss | < -15 dB @ 9 kHz to 30 MHz, typ. |
| Output return loss | < -20 dB @ 9 kHz to 30 MHz, typ. |
| Noise voltage | 1nV / √Hz, typ. |
| P1dBout | +15 dBm (indicated with yellow LED) |
| IP3out | +28 dBm |
| Connector type | N female |
| Power supply | 12 pieces standard AA NiMh cells (not supplied) |
| Charger | Mascot Type 2116 |
| Current consumption | 120 mA |
| Operation time | ca. 10 hours, depending on NiMh battery model |
| Indicators | LED indicators for Pwr On, Low Battery, Saturation |
| Dimensions | ⌀ 180 mm, height 52 mm |
| Weight | 1.7 kg |
| Tripod mount | ¼” thread |
