- Single-Channel High Voltage Linear Amplifiers from 70Vp-p up to 1600Vp-p
- Ultra-linear amplification
- High output power, up to 2A output current
- High Bandwidth, up to 5 MHz
- High Slew rate, up to 500V/μs
- Low output impedance, down to 0.1 Ohm
- Wide range of models to suit any performance and/or budget demand
P200
High Voltage High Current Linear Amplifier
The P200 is a general purpose linear amplifier with high voltage and high output current. Intended applications are piezoelectric positioning, electrostatic transducers and other high voltage instrumentation
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| High Voltage | ±100V |
| Gain | 10x |
| High Current | 1A |
| High Slew Rate | 30V/µs |
| Power Bandwidth | DC to ca 80kHz |
| Small Signal Bandwidth | DC to >200kHz |
