- Single-Channel High Voltage Linear Amplifiers from 70Vp-p up to 1600Vp-p
- Ultra-linear amplification
- High output power, up to 2A output current
- High Bandwidth, up to 5 MHz
- High Slew rate, up to 500V/μs
- Low output impedance, down to 0.1 Ohm
- Wide range of models to suit any performance and/or budget demand
P150
High Voltage High Current Linear Amplifier
The Pendulum Instruments High Voltage High Current Linear Amplifier P150 has a fixed amplification of 20 times and capable of unipolar high voltage output of 150V. Any signal source with amplitude up to ±10 V can be used as an input device. The input amplitude should normally be kept within range 0-75V. The High Voltage High Current Linear Amplifier P150 is equipped with a microfuse rated at 15 mA, which will be blown if the input voltage exceeds 300% of the maximum. The slew rate is set at the factory to 30 V/µs which yields the load limit of 100 nF. The continuous output current limit is 1 A and the output power limit is ca 125 W.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| High Voltage | +150V |
| Gain | 20x |
| High Current | 1A |
| High Slew Rate | 30V/µ |
| Power Bandwidth | DC to ca 60kHz |
| Small Signal Bandwidth | DC to >200kHz |
