- Single-Channel High Voltage Linear Amplifiers from 70Vp-p up to 1600Vp-p
- Ultra-linear amplification
- High output power, up to 2A output current
- High Bandwidth, up to 5 MHz
- High Slew rate, up to 500V/μs
- Low output impedance, down to 0.1 Ohm
- Wide range of models to suit any performance and/or budget demand
F70PV
Unipolar Variable Gain High Speed Amplifier
The F70PV is a broadband, high output current, general purpose linear amplifier designed for laboratory use. It is based on a fast operational amplifier with a feedback network chosen to give a voltage amplification of 10 times. Any function or arbitrary waveform generator can be used as an input device. The output is unipolar
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| High Voltage | ±70V 1A |
| Variable Gain | 0.10x |
| High Slew Rate | 500 V/µs |
| Broadband | DC to ca 5 MHz |
