- Single-Channel High Voltage Linear Amplifiers
- from 70Vp-p up to 1600Vp-p
- Ultra-linear amplification
- High output power, up to 2A output current
- High Bandwidth, up to 5 MHz
- High Slew rate, up to 500V/μs
- Low output impedance, down to 0.1 Ohm
- Wide range of models to suit any performance
- and/or budget demand
A-400
Single Channel High Voltage Linear Amplifier
The A400 is a general purpose linear amplifier designed for laboratory use. It is based on a fast high-voltage operational amplifier with a feedback network chosen to give a voltage amplification of 20 times. Any function or arbitrary waveform generator with output voltage up to ±10 V can be used as an input device. This device outputs high voltage signals at high frequency. It is, thus, imperative for the safe operation that the user understands the possibilities and limitations of the instrument. Isolated BNC output connector is used to comply with safety requirements.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| High Voltage | ±200V 150mA |
| Fixed Gain | 20x |
| Broadband | DC to ca 500kHz full scale |
| Low output impedance | <0.1Ω |
| High Slew Rate | 400V/µs |
