- Single-Channel High Voltage Linear Amplifiers
- from 70Vp-p up to 1600Vp-p
- Ultra-linear amplification
- High output power, up to 2A output current
- High Bandwidth, up to 5 MHz
- High Slew rate, up to 500V/μs
- Low output impedance, down to 0.1 Ohm
- Wide range of models to suit any performance
- and/or budget demand
A-800
Single Channel High Voltage Linear Amplifier
The A800 is a general purpose linear amplifier designed for laboratory use. It is based on a fast high-voltage operational amplifier with a feedback network chosen to give a voltage amplification of 100 times. Any function or arbitrary waveform generator with low output impedance and output voltage up to ±10 V can be used as an input device.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| High Voltage | ±800Vpp 60mA |
| Fixed Gain | 100x |
| Broadband | DC to ca 300kHz |
| Low output impedance | <0.1Ω |
| High Slew Rate | 500V/µs |
