- Wide frequency range 8 kHz to 8 GHz.
- Easy handling thanks to 10.4" touchscreen with user-friendly user interface.
- Optimum signal detection thanks to wide dynamic range (HDR) and excellent high-frequency (HF) properties.
- Measurements on site, remotely and in the laboratory.
- Analyze and evaluate based on classification criteria.
- Localization within milliseconds using automatic direction finding antennas.
- Integrated Windows for easy integration.
- Integrated Python for creating your own and individual applications.
SignalShark
Detect, Analyze and Localize Radio Signals
SignalShark - on the hunt for signals. Detect, analyze and localize radio signals. The SignalShark is highly efficient at detecting signals and entire frequency ranges. This is because the highly sensitive sensor technology developed by Narda detects changes in an increasingly complex radio spectrum in real time and without gaps. This makes the SignalShark the perfect instrument/tool for real-time spectrum analysis, monitoring and localization.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency Range | 8 kHz – 8 GHz wideband RF coverage 📡 |
| Real-Time Instantaneous Bandwidth | 40 MHz |
| Sweep / Scan Rate | > 50 GHz/s @ RBW = 1.6 MHz / > 32 GHz/s @ RBW = 100 kHz |
| Resolution Bandwidth (RBW) | 1 Hz – 800 kHz (Real-Time Spectrum) / 1 Hz – 6.25 MHz (Scan Spectrum) |
| Channel Bandwidth (Level Meter) | 25 Hz – 40 MHz |
| Detectors (Spectrum & Level Meter) | +Pk, RMS, –Pk, Avg, Sample |
| Probability of Intercept (POI) | 100% for signals > 3.125 μs @ RBW = 800 kHz |
| Spectrum Rate | ~1.6 million spectra/s (@ RBW = 800 kHz) |
| Dynamic Range | High dynamic range (HDR) receiver — optimal detection in complex environments (exact dB typically stated in extended datasheets) |
| Operating Time on Batteries | ~3 hours (typical) |
| Operating Temperature | approx. –10°C to +55°C |
| Weight (handheld) | ~3.8 kg (including batteries) |
