- Simple and efficient two step process for quick and accurate fiber cleaving.
- Recognized for its reliable and ergonomic design, offering durability and user comfort.
- Auto trash bin, automatically collects fiber waste, reducing cleanup time and maintaining a tidy workspace.
- Adjustable settings for different fiber types, allowing for flexible operation and consistent results.
V7+
High Precision Cleaver
V7 High Precision Cleaver is an instrument for high precision fiber cutting. V7 can be installed with a variety of holders for ribbon cable up to 12 fibers as well as universal holder which is applicable to 160µm to 900µm, 2mm-3mm and drop cable.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Type | Single fiber and ribbon fiber |
| Cladding Diameter | 125μm |
| Applicable Fiber Cable | Single fiber 160μm to 900μm, 2mm~3mm and drop cable / ribbon fiber 2 to 12 ribbon fiber cable |
| Cleaved Length | single fiber 5mm~20mm (Coating diameter ≤ 250μm) 10mm~20mm (Coating diameter >250μm) / ribbon (multi) fiber 10mm~20mm |
| Typical Cleaved Angle | Less than 0.5 Degrees | Typical Blade Life Span: Total 60,000 fiber cleaves (2,500 cleavers per each point, total 24 points) |
| Operation Steps | 2 Steps |
| Reclaim Function | Blade pushback |
| Holder | Single universal holder / ribbon replaceable holder |
