- Achieves fast splice times and efficient heating, ensuring high productivity in the field.
- Provides extended battery life, allowing for prolonged operation during fieldwork without frequent recharges.
- Bright operation lighting, equipped with powerful LED lights for optimal visibility, even in low-light conditions, ensuring precision in fiber splicing.
- Adjustable and secure holder supports a wide range of fiber sizes for flexible splicing.
- Easy to use interface with a touch screen for fast setup and smooth operation, reducing user training time.
- Real time tracking, built-in tracking system for monitoring splicing progress and fiber performance during the process.
- Allows efficient storage and management of splicing data, with the ability to generate detailed reports.
- Helps organize and track multiple tasks, improving workflow and ensuring no task is overlooked.
- Enables remote management and updates, ensuring the device is always performing at its best.
VIEW 8X
Premium Core Alignment Fusion Splicer
Embracing the standout qualities of the esteemed ViewX Series, the View 8X is a beacon of splicing innovation. It's equipped with IoT and GPS modules, ensuring state-of-the-art connectivity and enhanced security. Tailored for both large-scale operations and nuanced, detailed work, the View 8X delivers unmatched precision.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Model | VIEW 8X | Alignment Method: Core Alignment | Number of Fibers: Single | Applicable Fibers: SM (ITU-T G.652 & G.657), MM (ITU-T G.651), DS (ITU-T G.653), NZDS (ITU-T G.655) | Coating Diameter: 100µm – 3mm | Cladding Diameter: 80 – 150µm | Cleave Length: 5 – 16mm | Typical Splice Loss: SM: 0.01dB, MM: 0.01dB, DS: 0.03dB, NZDS: 0.03dB, G.657: 0.01dB | Return Loss: ≥ 60dB | Splice Programs: Max 300 modes | Automatic Calibration: Automatic Arc Calibration by air pressure & temperature | Electrode Life Span: 6000 Arc Discharges | Heating Programs: Max 100 modes | Protection Sleeve: 20mm – 60mm | Data Output: Cloud (View Pro Manager) + USB-C | Splice Memory: 20,000 splice data / 10,000 splice image | Battery: Capacity 9000mAh | Operation Cycle: 500 cycles (Splicing + Heating) | Monitor: 5.0" Color LCD display, Full Touch Screen | Application: x360, x520 | Size: 162 × 143 × 158mm | Weight: 2.68kg | Pull Test: 1.96 – 2.25N |
