- Frequency Range: 150 kHz to 230 MHz
- Designed for IEC / EN 61000-4-6
- 75 Ohm Coaxial Cables
- Individual calibration included
- Three Year Warranty
CDN C75E
Coupling Decoupling Network for 75 Ohm Coaxial Cable
The CDN C75E is used on coaxial lines with a nominal transmission line impedance of 75 ohms. The EUT and AE Ports are fitted with female, 75Ω BNC-type coaxial connectors. The RF Port is fitted with a female, 50Ω BNC-type coaxial connector. The outer surface of the network’s metallic enclosure is powder coated for durability, and is mounted onto, and internally bonded to, an untreated (conductive) stainless steel base plate. The base plate extends beyond the footprint of the network enclosure at the front and back, providing convenient access to effectively ground the network, which is essential for proper operation.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Product Name | Coupling Decoupling Network (CDN) |
| Compliant Test Standards | IEC / EN 61000-4-6 |
| Application | 75 Ohm Coaxial Cables |
| Frequency Range | 150 kHz to 230 MHz |
| RF Input Voltage | 40 V (Max) |
| RF Input Connector | 50 Ω BNC (Female) |
| Voltage Rating | 310 V AC / 440 V DC (Line to Ground) |
| Current Rating | 1 Amp (Max) |
| AE and EUT Connections | 75 Ohm Female BNC |
| 150 kHz - 26 MHz | 150Ω ± 20Ω |
| 26 MHz - 80 MHz | 150Ω + 60Ω / – 45Ω |
| 80 MHz - 230 MHz | 150Ω + 60Ω / – 60Ω |
| Voltage Division Factor | 9.5 dB +3 / -1 |
| Decoupling of Common Mode Disturbance | ≥ 40dB (EUT/AE) |
| Dimensions | 6 x 6 x 13 inches or 15.2 x 15.2 x 33 cm |
| Weight | 5 lbs. or 2.3 kg |
