- Frequency Range: 150 kHz to 230 MHz
- Current Ratings of 25, 50 and 100 Amps
- Single-Line (M1), Two-Line (M2),
- Three-Line (M3), Four-Line (M4)
- and Five-Line (M5) Models
- Fully Compliant with CISPR 16-1-2 and IEC 61000-4-6
- Three-Year Warranty
CDN-M525E
Five Conductor Power Line 25 Amp CDN
CDN-M525E Coupling Decoupling Network has a current rating of 25 Amps. It has a 5 conductors power cable capability. The disturbance signals are coupled to each conductor in the supply lines according to IEC/EN 61000-4-6 standard for immunity testing. Com-Power's CDN-M325E covers the frequency range of 150 kHz - 230 MHz.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Product Name | Coupling Decoupling Network (CDN) |
| Compliant Test Standards | IEC / EN 61000-4-6 |
| Application | Five conductor power cable |
| Frequency Range | 150 kHz to 230 MHz |
| RF Input Voltage | 40 V (Max) |
| RF Input Connector | 50 Ω BNC (Female) |
| Voltage Rating | 250 V AC / 350 V DC (Line to Ground) |
| Current Rating | 25 Amps AC / 17 Amps DC (Max) |
| AE and EUT Connections | 4 mm shrouded banana sockets |
| 150 kHz - 26 MHz | 150Ω ± 20Ω |
| 26 MHz - 80 MHz | 150Ω + 60Ω / – 45Ω |
| 80 MHz - 230 MHz | 150Ω + 60Ω / – 60Ω |
| Voltage Division Factor | 9.5 dB +4 / -1 |
| Decoupling of Common Mode Disturbance | ≥ 40dB (EUT/AE) |
| Dimensions | 6 x 6 x 13 inches or 15.2 x 15.2 x 33 cm |
| Weight | 5 lbs. or 2.3 kg |
