- Frequency Range: 150 kHz to 230 MHz
- Current Ratings of 25, 50 and 100 Amps
- Single-Line (M1), Two-Line (M2), Three-Line (M3), Four-Line (M4) and Five-Line (M5) Models
- Fully Compliant with CISPR 16-1-2 and IEC 61000-4-6
- Three-Year Warranty
CDN-M325E
CDN for 3 Conductors Powerline
The CDN-M325E is an M-series Coupling/Decoupling Network designed for three-conductor power cables, compliant with IEC/EN 61000-4-6. It couples disturbance signals to each conductor for conducted immunity testing. The CDN has a current rating of 25 A and operates over a frequency range of 150 kHz to 230 MHz. It is optionally available with two common-mode (shorting) adapters, used during test level calibration and for measuring electrical performance parameters such as impedance, phase, voltage division factor, and isolation.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Product Name | Coupling Decoupling Network (CDN) |
| Compliant Test Standards | IEC / EN 61000-4-6 |
| Application | Three conductor power cable |
| Frequency Range | 150 kHz to 230 MHz |
| RF Input Voltage | 40 V (Max) |
| RF Input Connector | 50 Ω BNC (Female) |
| Voltage Rating | 250 V AC / 350 V DC (Line to Ground) |
| Current Rating | 25 Amps AC / 17 Amps DC (Max) |
| AE and EUT Connections | 4 mm shrouded banana sockets |
| 150 kHz - 26 MHz | 150Ω ± 20Ω |
| 26 MHz - 80 MHz | 150Ω + 60Ω / – 45Ω |
| 80 MHz - 230 MHz | 150Ω + 60Ω / – 60Ω |
| Voltage Division Factor | 9.5 dB +4 / -1 |
| Decoupling of Common Mode Disturbance | ≥ 40dB(EUT/AE) |
| Dimensions | 6 x 6 x 13 inches or 15.2 x 15.2 x 33 cm |
| Weight | 5 lbs. or 2.3 kg |
