- Frequency Range: 10 kHz to 400 MHz
- Complies with MIL-STD-461 and RTCA DO-160
- Current Injection & Monitoring capability
- Split-core ferrite design for easy cable insertion
- Three-year warranty
CLCI-400
10 kHz–400 MHz Bulk Current Injection Probe
The CLCI-400 Bulk Current Injection Probe is designed for conducted susceptibility testing in accordance with RTCA DO-160 Section 20 and MIL-STD-461 (CS114, CS115, CS116). It operates efficiently over a 10 kHz to 400 MHz frequency range, achieving required test levels with less than 60 W of forward power. The probe features a hinged split-core ferrite design, allowing easy installation of cables or cable bundles, making it more convenient to use than non-split-core probes.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Product | Bulk Current Injection Probe |
| Frequency Range | 10 kHz to 400 MHz |
| Window Diameter | 1.575” (40 mm) |
| Outside Diameter | 5.75” (146 mm) |
| Width | 2.75” (70 mm) |
| Weight | 4.5 lbs (2.04 kg) |
| Input Connector | Type-N (female) |
| Maximum Input Power | 100 Watts (continuous) |
| Maximum Core Temperature | 284º F (140º C) |
