- Frequency Range: 150 kHz to 230 MHz
- Current (maximum continuous, per line): 100 Amperes
- Number of Power Line Conductors: Two-Line (M2)
- Fully Compliant with CISPR 16-1-2 and IEC 61000-4-6
- Three-Year Warranty
CDN-M2100
Powerline 100 Amp CDN for Two Conductors
The CDN-M2100 is an M-series Coupling Decoupling Network designed for two-conductor power cables, with a current rating of 100 A and a frequency range of 150 kHz to 230 MHz. It is recommended for power supply connections and couples disturbance signals onto each conductor in accordance with EN 61000- -6. The CDN is optionally available with two common-mode (shorting) adapters, used during test level calibration and for measuring electrical performance parameters such as impedance, phase, voltage division factor, and isolation.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Product Name | Coupling Decoupling Network (CDN) |
| Compliant Test Standards | IEC / EN 61000-4-6, CISPR 16-1-2 |
| Application | Two conductor power cable |
| Frequency Range | 150 kHz to 230 MHz |
| RF Input Voltage | 40 V (Max) |
| RF Input Connector | 50 Ω BNC (Female) |
| Voltage Rating | 250 V AC / 350 V DC (Line to Ground) |
| Current (maximum continuous, perline) | 100 Amperes |
| EUT/AE Power Ports | Multi-Contact ID/S6AR-N-B4S |
| 150 kHz - 26 MHz | 150Ω ± 20Ω |
| 26 MHz - 80 MHz | 150Ω – 45Ω / + 60Ω |
| 80 MHz - 230 MHz | 150Ω + 60Ω / – 60Ω |
