- Frequency range: 10 kHz to 100 MHz
- 40 mm window fits large cables and bundles
- Split-core design for easy clamp-on access
- Complies with IEC 61000-4-6 and CISPR 16-1-2
- Supports up to 100 watts continuous RF power
- Enables both injection and monitoring
- 1:1 turns ratio for accurate current transfer
- Works with FCLC-100 calibration fixture
- Durable design with 140°C max core temperature
- Includes 3-year manufacturer warranty
CLCI-100
Conducted Immunity Testing Probe
The CLCI-100 Bulk Current Injection Probe is designed for conducted RF immunity testing, compliant with IEC 61000-4-6 and CISPR 16-1-2 standards. It features a hinged split-core ferrite design, allowing easy placement of cables or cable bundles into the probe. The CLCI-100 provides high efficiency, achieving test levels up to 10 Vrms with less than 100 W of forward power. It supports up to 100 A window current and 100 W RF input power, making it suitable for demanding immunity test applications.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency Range | 10 kHz to 100 MHz |
| Window Diameter | 1.575” (40 mm) |
| Outside Diameter | 5.75” (146 mm) |
| Width | 2.75” (70 mm) |
| Weight | 4.5 lbs (2.04 kg) |
| Input Connector | Type-N (female) |
| Maximum Input Power | 100 Watts (continuous) |
| Maximum Core Temperature | 284ºF (140ºC) |
| Turns Ratio | 1:1 |
