- Transmit/Receive Loop Antenna Set for MIL-STD-461, RS101 Calibration/Test
- Frequency Range: 30 Hz to 100 kHz
- Convenient, Fixed Mounting Arrangement for Receive Loop onto Transmit Loop for Accurate Calibration of Test Level
- Individual Calibration per SAE ARP958 Included
AL-RS101-TX
Mil-Std Loop Antenna Set
The AL-RS101-TX is a transmitting loop antenna constructed with 20 turns of 12-gauge enamel-insulated copper wire and a 12 cm mean diameter. It is mounted on an elongated PTFE (Teflon) structure to maintain the required 5 cm spacing from the Equipment Under Test (EUT) when placed flush against its surface. The antenna uses 4 mm banana jack input terminals and includes a mounting mechanism for precise positioning of the AL-RS101-RX antenna during calibration. The AL-RS101-TX can handle RF currents up to 15 A, generating a maximum magnetic flux density of 183.1 dBpT at 5 cm. The AL-RS101-RX is a receiving loop antenna used for RS101 calibration, designed to measure the magnetic field produced by the transmit loop. It features a 51-turn, electrostatically shielded coil made of Litz wire and is equipped with a female BNC output connector.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| AL-RS101-TX Frequency Range | 30 Hz to 100 kHz |
| Loop Diameter | 12 cm |
| Number of Turns | 20 turns |
| Wire Type | 12 AWG (enamel insulated) |
| Loop Shielding | N/A |
| Resistance of Wiring | 40 mΩ |
| Inductance of Wiring | 60 µH |
| Maximum Input Current | 15 A (continuous) |
| Connectors | (2) Banana Jacks |
| Specifications | MIL-STD-461, RS101 |
| Weight | 2.2 lbs (1 kg) |
| AL-RS101-RX Frequency Range | 30 Hz to 100 kHz |
| Loop Diameter | 4 cm |
| Number of Turns | 51 turns |
| Wire Type | 7-strand, 41 AWG Litz |
| Loop Shielding | Electrostatic Shield |
| Resistance of Wiring | 4 Ω |
| Inductance of Wiring | 180 µH |
| Maximum Input Current | N/A |
| Connectors | BNC (female) |
| Specifications | MIL-STD-461, RS101 |
| Weight | 0.26 lbs (0.12 kg) |
