- Broadband - For sweep measurements
- High Gain - Lower Floor Noise for Emissions
- Three Year Warranty
- Individual Calibration
AH-118
Wide Band Horn Antenna
The AH-118 Double Ridge Horn Antenna is designed for EMI and regulatory compliance testing, meeting standards such as FCC, CE, MIL-STD-461, RTCA DO-160, FDA, and SAE. It is also suitable as a transmitting antenna for radiated immunity testing, with a power handling capability of up to 300 watts. Additionally, the AH-118 is commonly used as a substitution antenna to determine ERP and EIRP of RF transmitters for FCC/ETSI certification. It can also be used for site comparisons, shielding effectiveness tests, field monitoring, and general RF measurements.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency Range | 700 MHz - 18 GHz |
| Power | 300 Watts continuous |
| VSWR | 2.0 : 1 |
| Polarization | Linear |
| Impedance | 50 Ω |
| Connector type | N type (f) |
| Weight | 4 lb. max. |
| Size | 7.8” X 9.5” X 5.6” / 19.8 x 24.1 x 14.2 cm |
