V110-1-R

V110-1-R is designed to connect to a 0.15 mm microstrip trace on Alumina. The installation note for the V110-1 shows how to make connections using parallel-gap welding, wire bonding or soldering.

Key capabilities and advantages

▼

Provides stress relief: Protects circuits from temperature variations, shock, and vibration.
High-quality microwave connection: Connects to a 0.24 mm pin without soldering.
Optimized for V Connectors: Designed to operate up to 65 GHz.

Technical specifications and parameters

▼

Model	V110-1-R
Intended Use	Microstrip or coplanar waveguide circuits with trace width ≥ 0.15 mm on alumina or Duroid substrates
Frequency Range	DC to 65 GHz – compatible with V Connector system performance
RoHS Compliance	Yes
Environmental & Reliability	Complies with MIL-STD-202F (thermal shock, humidity, salt spray, vibration, shock)
