- Wideband RF performance: Supports clean, mode-free signal transmission up to 65 GHz with very low VSWR and insertion loss.
- Precision flange mounting: Two-hole design ensures stable mechanical alignment; flange tolerances must meet concentricity specs (~±0.038 mm).
- Solderless microstrip launch interface: Simplifies installation while minimizing signal contamination.
V103M-R
The V103M-R is RoHS compliant. It contains less than the Maximum Concentration Values (MCVs) for Lead, Mercury, Cadmium, Hexavalent Chromium, PBB and PBDE per EU directive 2002/95/EC.
The following RoHS exemption applies: Lead as an alloying element in copper containing up to 4% (40000PPM) lead by weight.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Model | V103M-R |
| Connectors | V(m) flange launcher connector |
| Mounting | Two mounting holes |
| Excellent Performance | up to 65 GHz |
| Compatibility | with 2.4 mm |
| Complete Testability | on existing network analyzers |
