- Provides ±0.3 dB (typ.) total level accuracy
- 9 kHz to 3.6 GHz/6 GHz/13.5 GHz/26.5 GHz/43 GHz frequency range
- Various options can be installed
- Spectrum analyzer supporting built-in signal analyzer with FFT technology, vector signal generator, analog signal generator and audio analyzer (options)
- Offers modulation analysis, such as LTE, W-CDMA, WLAN, Vector Modulation and Analog Modulation (with optional software)
- Excellent eco-friendly product with low power consumption of 110 VA min.
MS2830A
Spectrum Analyzer/Signal Analyzer
MS2830A is the multifunctional Signal Analyzer and offers excellent cost-performance with a full line of test applications. The MS2830A-040/041/043 has an upper frequency limit of 3.6 GHz/6 GHz/13.5 GHz and they are ideal for evaluating various digital wireless equipment, including cellular and WLAN, as well as for developing, manufacturing, and maintaining analog and digital PMR/LMR.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency Range (model-dependent) | 9 kHz – 3.6 GHz (MS2830A-040), 9 kHz – 6 GHz (MS2830A-041), 9 kHz – 13.5 GHz (MS2830A-043), 9 kHz – 26.5 GHz / 43 GHz (MS2830A-044 / MS2830A-045) |
| Resolution Bandwidth (RBW) | 1 Hz to 3 MHz (selectable) |
| Displayed Average Noise Level (DANL) | Approximately –153 dBm/Hz (typical, with preamp ON) |
| Amplitude Accuracy | ±0.3 dB (typical) to ±1.0 dB (depending on frequency and configuration) |
| Level Measurement Range | From DANL to +30 dBm (input level without attenuation) |
| Third-Order Intercept (TOI) | +15 dBm or higher (typical) |
| Sweep Speed | High-speed sweep for fast signal search and measurement |
| Frequency Span | 0 Hz (CW mode) to maximum frequency of model |
