- High-end OTDR performance in a pocket-size package.
- Exclusive integrated launch fiber provides accurate initial connector measurement.
- Complete PON testing through splitters up to 1 x 64.
- High resolution, widescreen color display.
- Compact and lightweight design for maximum portability.
MU909014A1/B/B1/C/C6
Introducing the handheld OTDR that does not compromise performance – the µOTDR MU909014A1 from Anritsu.
With performance that rivals traditional OTDRs that are four times the size and more than double the price, it features 5 cm resolution for accurate mapping of events, deadzones of less than 1 meter (3-feet) and a dynamic range of up to 32.5 dB – enough to test over 150 km or PON-based FTTx networks featuring up to a 1 x 64 split.
The MT9090A also takes portability to a new level by being the first handheld OTDR that truly fits in the palm of your hand.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Center Wavelength | 1310/1550 ±20 nm - 1625 ±15 nm, 1310/1550 - ±20 nm, 1650 ±15 nm, 1310/1490/1550 ±20 nm, 1310/1550 ±20 nm - 1625 ±15 nm, 1310/1550 ±20 nm - 1650 ±15 nm. |
| Dynamic Range | 38 dB/37 dB/35 dB. |
| Dead Zone | Fresnel ≤0.8 m (Typical), Backscatter ≤4.0 m (1310 nm, Typical). |
| Number of Sampling Points | <250,001 pts. |
| Sampling Resolution | 2 cm (min.). |
| Testing Modes | OTDR (Full automatic, Manual, Real time), Power Meter. |
| Environment | Operating temperature –10°C to +50°C, <95% (no condensation). |
