MG3710E

The Vector Signal Generator MG3710E is a best-of-class, multi-function, signal generator with excellent RF and baseband performance.

It features wideband vector modulation and offers built-in baseband waveform generation with large-capacity memory.

It supports all key mobile communications and wireless LAN standards, and the exceptional performance required for emerging and proprietary wireless technologies.

Features

Key capabilities and advantages

▼

Vector Signal Generator supporting frequencies of 100 kHz to 2.7/4/6 GHz.
ACLR: -68 dBc (W-CDMA, Test-Model 1, 64DPCH, ≤ +5 dBm).
Output Level: +23 dBm (CW, 400 MHz to 3 GHz).
Switching Time: < 600 µs (List/Sweep mode).
Built-in wideband (160 MHz / 120 MHz) baseband signal generator.
Dual RF (Optional) provides two independent RF outputs.
Dual Waveform Memory (Optional) enables two independently modulated signals per RF Output.
Generate and output modulation signals of various communication systems such as 5G NR (sub-6 GHz) TDD/FDD, LTE-Advanced TDD/FDD (Optional).
