- Sub-nanosecond time accuracy.
- Compact size.
- Distance range: over 80 km using fiber.
- Robustness & Redundancy.
- Dynamic calibration.
- Remote monitoring & upgrade.
- Programmable trigger.
White Rabbit LEN
The cost effective node to distribute synchronization
WR LEN is the competitive White Rabbit alternative capable of supporting daisy chain configurations. It allows a cost effective solution to distribute PPS/10MHz signals or IRIG-B protocol to your equipment. Optional: 2xμ-DB9 connector for PPSs & 10MHz fan-out or configurable output triggers.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Size | 54 x 105 x 135 mm. |
| Power | 5V DC, 1.5 A – 7.5W max. |
| Environmental Conditions | Temperature : -10ºC ~ +50ºC. |
| Humidity | 0% ~ 90% RH. |
| Timing Protocols / Interfaces | White Rabbit – Dual optical fiber Ethernet 1G interfaces. IRIG-B / PPS I/O – Digital LVTTL (3.3V) Selectable operation. |
| Frequency I/O | 10 MHz programmable input/output. |
