- Sub-nanosecond time accuracy.
- 18 SFP 1GbE ports.
- Time and frequency distribution.
- Distance range over 100km in 1-hop.
- First device supporting White-Rabbit protocol.
- Large community of users.
White Rabbit Switch v3.4.
The key element of the White Rabbit network
It is the first commercial available device developed with the White Rabbit (WR) Technology. It distributes Time and Frequency within a sub-nanosecond accuracy to thousands of nodes through standard optical fiber over Metro Area network distances. It also works as a basic data switch. It is the basic element for scientists and technologists looking for experimenting with WR technology and to evaluate features like deterministic time transfer or dynamical self-calibration of optical fiber links.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Size | 447 mm x 44 mm x 223 mm. |
| Power Input | 100-240VAC, 2.0A 50-60 Hz. |
| Power Output | 12V DC, 6.66A – 80W max. |
| Certifications | ISO-9001, ISO-14001, CE, RoHS,FCC,SE. |
| Environmental Conditions | Temperature : -10ºC ~ +50ºC. |
| Humidity | 0% ~ 90% RH. |
| Timing Protocols and Front Panel Clocks I/O | 5 SMC coaxial connectors, 10 MHz reference clock input (GPS/Cesium), 10MHz & 62.5 MHz output reference clock, 1xPPS Input & 1xPPS Output. |
| Ports | 18 x SFP cages. SFP transceivers are not included in all packages. Recommendation – 1.25Gbps, 1490/1310 nm, Single Fiber Bi-directional SFP. |
| Management | 100Base-T Ethernet (Remote) / USB Mini-B (Local) |
