- Sub-nanosecond time accuracy.
- WR, PTPv2 and NTP over optical interfaces.
- Extended management and monitoring.
- Distance range over 80 km using fiber.
- Failover mechanisms & Holdover.
- Robustness & Redundancy.
- Low jitter/phase noise frequency dissemination.
- Precise timing sources monitoring capability.
- 32 BNC configurable outputs xPPS/10MHz/IRIG-B with selectable 50Ω termination.
- Ethernet : 2x 10/100/1000 Base-T RJ45 (Management, NTP)
- Clocks I/O : 5xSMA coaxial connectors (3V/50Ω): 10 MHz SIN OUT, CLK OUT(LVTTL), PPS OUT/IRIG-B (LVTTL), PPS IN (LVTTL), 10MHz IN (TTL/CMOS/ ECL/clippedsine).
- Fanout : 32x BNC configurable outputs divided in 2 blocks:(1.7V/50Ω): A&B: 10MHz/xPPS/IRIG-B (LVTTL, with selectable 50Ω termination) C&D: xPPS/IRIG-B (LVTTL, with selectable 50Ω termination).
- LCD : Information panel for alerts & network configuration.
White Rabbit ZEN TP-32BNC
The reliable node that provides multiple legacy 10MHz/xPPS timing outputs.
It is the versatile standalone node that provides the White Rabbit features to a wide range of applications making use of its redundant connections. The WR-ZEN TP-32BNC easily distributes time and frequency to other equipment by implementing standard timing protocols such as PTP, NTP, IRIG-B, etc.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Size | 428 x 88 x 220 mm |
| Environmental Conditions | Temperature : -10ºC ~ +50ºC |
| Humidity | 0% ~ 90% RH |
