- g-tip-over test : 2 x 10-10 / g on worst sensitive axis.
- Low magnetic sensitivity (Option code LM) < 5 x 10-11 / g / all axis.
- Vibration Sensitivity – < 1 x 10-9 / g / (Option code Q3).
- Very low temperature sensitivity.
- Excellent short term stability.
- Fast warm-up.
- Small volume / low profile.
LPFRS Rubidium Oscillator
Low-profile, high-performance rubidium oscillator
The LPFRS is RoHS compliant through the NIE exemption of the RoHS Directive 2011/65/EU, Article 4.6/Annex III-7(b), allowing exemptions of Pb free soldering for specific applications such as telecom, including servers, storage array systems, network infrastructure equipment for switching, signalling, transmission, and network management for telecommunications.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Product Volume | 13 in3 |
| Freq. offset over temp. range | ±1×10-10 |
| Stability | 1×10-12/100 sec. |
| Long term stability | < 5×10-10/year |
| Low warm-up current | < 0.9A |
