- One-day holdover below 1µs.
- High accuracy and stability atomic frequency clock.
- Low SWaP-C (Size, Weight, Power and Cost).
- Enhanced MAC (Miniature Atomic Clock) technology.
- Frequency Stability: ADEV : 1s < 4E-11 (Option S).
- Cell lifetime/MTBF: 10 years / 155860 hours at +25°C.
- Aging (After 30 days): Per day < (option A) 5E-12 / day.
mRO-50 Ruggedized
Low SWaP-C Mini-Rubidium Oscillator
The mRO-50 Ruggedized is a breakthrough microwave optical double resonance (MODR) low SWaP-C Miniaturized Rubidium Oscillator designed to meet the latest commercial, military and aerospace requirements where time stability and power consumption are critical.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Size | 50.8 x 50.8 x 20 mm (± 0.4 mm) |
| Weight | 80 g max |
| Volume | < 52 cc |
| Operating Temperature | -40°C to +80°C |
| Input Power | 0.45W steady state 1.5W start-up |
| DC power | 0.45W @5V and 0.36W @3.3V (option) |
| Vibration | 7.7 grms/axis per MIL-STD-810, Fig 514.7E-1, Category 24 |
