- Fixed attenuation values for repeatable signal reduction.
- Wide frequency coverage from DC to 3 GHz.
- Low VSWR (<1.3) for minimal reflection.
- Stable attenuation performance across all models.
- Suitable for RF testing, EMC measurements, signal conditioning.
- N-male to N-female connectors for easy integration.
TBATT-N-10
Single Attenuators
The 10 W series offers compact fixed attenuation options ideal for lower power RF bench setups and test systems where controlled signal reduction is required.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Power rating | 10 W |
| Frequency range | DC to 3 GHz |
| RF connector | N-male to N-female |
| VSWR | <1.3 |
| Attenuation values | 3 dB, 6 dB, 10 dB, 20 dB, 30 dB |
| Attenuation tolerance | 3 dB, 6 dB, 10 dB: ±0.5 dB/20 dB: ±0.8 dB/30 dB: ±1 dB |
