- Snap-on design.
- Easy and fast installation.
- Non-intrusive conducted emission current measurement.
- Suitable alternative or complement to LISNs.
- Ideal for EMC diagnostics and troubleshooting.
- Fixed-aperture and snap-on versions available.
- Individually characterized trans-impedance.
TBCP2-30M1000
Snap On RF Current Monitoring Probes
The TBCP2-30M1000 is a snap-on RF current monitoring probe, expanding the Tekbox product range of affordable EMC pre-compliance test equipment. The probe is characterized over the frequency range from 10 kHz to 1 GHz. It has a 3 dB bandwidth from 30 MHz – 900 MHz and a transfer impedance of 22 dBΩ ± 2 dBΩ from 25 MHz – 1 GHz.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Characterized frequency range | 10 kHz to 1 GHz |
| 3 dB bandwidth | 30 MHz to 900 MHz |
| Transfer impedance | 22 dBΩ ± 2 dBΩ from 25 MHz – 1 GHz |
| Max. primary current (DC – 400Hz) | >50A, see graph in chapter 5 |
| Max. primary current (RF) | 10 A |
| Max. pulse current | 50A |
| Current-time product | 0.007 As |
| Max. core temperature | 125 °C |
| Connector type | N female |
| Aperture diameter | 32 mm |
| Outside diameter | 73 mm |
| Height | 20 mm |
| Weight | 320 g |
