- Selective monitoring of high-frequency fields from 9 kHz to 30 MHz
- Ideal for monitoring LW, MW, SW broadcast antennas
- Measures both electric (E-field) and magnetic (H-field) components
- Programmable frequency bands for targeted monitoring
- Spectrum mode and frequency-table mode for flexible analysis
- Supports RMS, AVG, and long-term trend measurement
- Capable of autonomous operation via battery or solar power
- Remote monitoring enabled via Wi-Fi, RS-232, or optical fiber
- Configurable data logging intervals for continuous exposure assessment
- Rugged and weatherproof design for permanent outdoor installation
AMS-8063
EMF 24/7 Area Monitor
The selective AMS-8063 monitors high-frequency fields from 9 kHz to 30 MHz. Due to its unique characteristics, the AMS-8063 is particularly suitable for monitoring antenna systems in the vicinity of LW, MW and SW transmissions.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency range | 9 kHz – 30 MHz |
| Measurement range (electric field) | 0.1 – 1000 V/m |
| Measurement range (magnetic field, Mode A 9 kHz – 3 MHz) | 0.03 – 300 A/m |
| Measurement range (magnetic field, Mode B 300 kHz – 30 MHz) | 0.003 – 30 A/m |
| Resolution | 0.01 V/m, 0.1 mA/m |
| Sensitivity | 0.01 V/m |
| Measurement units | V/m, A/m |
| Measurement type | Electric and magnetic field monitoring (selective) |
| Data storing interval (Table mode) | 1–1440 minutes (selectable) |
| Spectrum logging interval (Spectrum mode) | selectable (10 min – 24 hours or threshold-based) |
| Communication interfaces | Wireless LAN, RS-232, Optical Fiber (model dependent) |
| Power supply | Rechargeable battery + optional solar panel |
| Operating conditions | Outdoor long-term monitoring, weatherproof housing |
